TECHNICAL SPECIFICATIONS
MS-100
RF SECTION
MODULATION: FM, 75kHz deviation
FREQUENCY SELECTION: 88.1 to 107.5 MHz
FREQUENCY PRECISION: .005%
MAXIMUM POWER: 250µV/m @ 3 m (FCC Part 15 compliance)(RSS-210)
: 1.5 miliWatts (DOC RSS-123)(Canada only).
SPURIOUS REJECTION: 45 dB min.
FREQUENCY STABILISATION DELAY: 4 SECONDS @ 88.1mhz
AUDIO SECTION
FREQUENCY RESPONSE: 20 - 20,000 Hz
HARMONIC DISTORTION: 0.05% max.
SIGNAL TO NOISE RATIO: 70 dB min.
DYNAMIC RANGE: 80 dB min.
INDICATORS: Power status, over modulation status.
CONTROLS: Modulation volume, frequency selection(10 bit dip switch).
MISC
POWER SUPPLY: 115/16vAC @ 300Ma.
DIMENSIONS: 9.8" X 6.3" X 1.6"
Decade Transmitters inc,Sherbrooke,Quebec,Canada.All rights reserved 1997.
