MD‐CROSSOPERATINGMANUALVERSION1.0
Copyright©2013DecimatorDesignPtyLtd,Sydney,Australia
4
MainMenus
UponpoweruptheunitwillstartintheMainMenupointingtoInputStatus.
TheMainMenusare:
1. InputStatus
2. Control
3. Scaling/TPG
4. Audio
5. AudioMeters
6. Graticules
7. TextOverlays
8. Setup
Pressthe<and>buttonstomoveleftorrightthroughthe
menus.
ToenterintoamenupresstheENTERbutton.

Notes:
1.) Defaultsarehighlightedinyellow.
2.) Whenanoptionischanged,ahighlightedSwillappearinthetoprightoftheLCDscreenand
willdisappearwhentheoptionsaresavedafter10seconds.Avoidpoweringdowntheunit
duringthistime.
3.) YoucanalwaysreturntotheMainMenubypressingtheBACK
buttontwice.
4.) Asyoumovethroughthemenuschangingparameters,theywillbeinstantlyappliedtothe
outputsignal.
5.) ScalerandDUC(DownUpCrossconversion)areusedinterchangeablyintheMENUs.

InputStatus:(HasnoSUB‐MENUs)

Input Status
S:3G 1080p59.94
H:ED 480p59.94
D:HD 1080i59.94
MainMenu <==
CurrentSDIinputformat
CurrentHDMIinputformat
CurrentScalingoutputformat
TheinputshowsthecurrentSDIandHDMIinputstatusaswellastheDUCoutputformatstatus.

Control:(HasSUB‐MENUs)

Control
SDI OUT SOURCE
SDI IN
MainMenu <==
SubMenu
ParameterWindow
WhenhighlightedintheMainMenu,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe8menusbelowandpressthe
BACKbuttontogobacktotheMainMenuwhenfinished.
Thecurrentvalueforeach
SubMenuisshownintheParameterWindow.

1.Control/SDIOUTSOURCE(Parameter)
ThisisthecurrentsourcefortheSDIoutput.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingsources:
1.) SDIIN
2.) HDMIIN
3.) Scaler/TPG OutputfromScaler

2.Control/HDMIOUTSOURCE(Parameter)
ThisisthecurrentsourcefortheHDMIoutput.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingsources:
1.) SDIIN
2.) HDMIIN
3.) Scaler/TPG OutputfromScaler
