MD‐CROSSOPERATINGMANUALVERSION1.0
Copyright©2013DecimatorDesignPtyLtd,Sydney,Australia
5
3.Control/HDMIOUTTYPE(Parameter)
ThisisthecurrentHDMIoutputtype.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingtypes:
1.) DVIRGB444 DVI‐DRGB4:4:4
2.) HDMIRGB4442C HDMIRGB4:4:4with2‐ChannelsofAudio
3.) HDMIYCbCr4442C HDMIYCbCr4:4:4with2‐ChannelsofAudio
4.) HDMIYCbCr4222C HDMIYCbCr4:2:2with2‐ChannelsofAudio
5.) HDMIRGB4448C HDMIRGB4:4:4with8‐ChannelsofAudio
6.)
HDMIYCbCr4448C HDMIYCbCr4:4:4with8‐ChannelsofAudio
7.) HDMIYCbCr4228C HDMIYCbCr4:2:2with8‐ChannelsofAudio
4.Control/DUC/TPGSource(Parameter)
ThisisthecurrentsourceforboththeScalerandtestpatterngenerator.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingsources:
1.) SDIIN
2.) HDMIIN
5.Control/DUC/TPGREF(Parameter)
ThisisthecurrentreferenceforboththeScalerandtestpatterngenerator.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) SOURCE
2.) FREE‐RUN Freerunwithoutareference
6.Control/APPLYOVERLAYTO(Parameter)
Thisisthevideosourcethattheoverlaysareappliedto.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) SDIIN
2.) HDMIIN
3.) Scaler/TPG OutputfromScaler
4.) None
7.Control/LCDOFFTIME(Parameter)
ThisistimetakenfortheLCDlighttoturnoffafterthelastbuttonpress.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingtimes:
1.) 5seconds
2.) 15seconds
3.) 30seconds
4.) 1minute
5.) 5minutes
6.) 10minutes
7.) 30minutes
8.) Never
8.Control/BACK2STATUSTIME(Parameter)
ThisistimebeforethemainmenuisreturnedtoInputStatusafterthelastbuttonpress.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingtimes:
1.) 5seconds
2.) 15seconds
3.) 30seconds
4.) 1minute
5.) 5minutes
6.) 10minutes
7.) 30minutes
8.) Never
