MD‐CROSSOPERATINGMANUALVERSION1.0
Copyright©2013DecimatorDesignPtyLtd,Sydney,Australia
8
8.Scaling/TPG/1080i=1080psf(Parameter)
Thisindicatesif1080iisrecognisedas1080psfinsteadof1080i.As1080iand1080psfhavethesame
formatstructure.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) No 1080iinput=1080i
2.) Yes 1080iinput=1080psf
9.Scaling/TPG/HorzFilter(Parameter)
Thisindicatesthelevelofthehorizontalanti‐aliasingfilterpriortotheScaler.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) Auto
2.) None
3.) Low
4.) Medium
5.) High
10.Scaling/TPG/SDIOutTestAud(Parameter)
ThisselectsthetesttonegeneratorontheSDIoutput.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) Off
2.) 1kHzTone
3.) 1kHzTone/500HzTone/1kHzBrokenTone/500HzBrokenTone
4.) Left=1kHzTone,Right=1kHzBrokenTone
11.Scaling/TPG/HDMIOutTestAu(Parameter)
ThisselectsthetesttonegeneratorontheHDMIoutput.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) Off
2.) 1kHzTone
3.) 1kHzTone/500HzTone/1kHzBrokenTone/500HzBrokenTone
4.) Left=1kHzTone,Right=1kHzBrokenTone
Audio:(HasSUB‐MENUs)
Audio
SDI Out Pair 1
Group 1 Pair 1
MainMenu <==
SubMenu
ParameterWindow
WhenhighlightedintheMainMenu,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe12menusbelowandpress
theBACKbuttontogobacktotheMainMenuwhenfinished.
Thecurrentvalueforeach
SubMenuisshownintheParameterWindow.
Thefollowingsubmenusareavailable:
1.) SDIOutPair1
2.) SDIOutPair2
3.) SDIOutPair3
4.) SDIOutPair4
5.) SDIOutPair5
6.) SDIOutPair6
7.) SDIOutPair7
8.)
SDIOutPair8
9.) HDMIOutPair1
10.) HDMIOutPair2
11.) HDMIOutPair3
12.) HDMIOutPair4
