Decimator MD-HX - Scaling; Scaling; Output Format; Scaling; SD2 SD ASPECT

MDHXOPERATINGMANUALVERSION1.0
Copyright©2014DecimatorDesignPtyLtd,Sydney,Australia
7
Scaling:(HasSUBMENUs)

Scaling
Output Format
HD 1080i59.94

MainMenu<==
SubMenu
ParameterWindow
WhenhighlightedintheMainMenu,presstheENTERbuttontoenterthissubmenu.
Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe11menusbelowandpress
theBACKbuttontogobacktotheMainMenuwhenfinished.
ThecurrentvalueforeachSubMenuisshownintheParameterWindow.

1.Scaling/OutputFormat(HasSUBMENUwithparameter)
ThisisthecurrentoutputformatfortheScaler.
Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissubmenu.
Pressthe<and>buttonstomoveleftorrightthroughthe28videoformatslistedbelowandthe
BACKbuttontoleavethisSUBMENU.
1.SD720x487i59.94
11.HD1920x1080psf24
21.HD1280x720p30
2.SD720x576i50
12.HD1920x1080psf23.98
22.HD1280x720p29.97
3.ED720x487i59.94
13.HD1920x1080p30
23.HD1280x720p25
4.ED720x576i50
14.HD1920x1080p29.97
24.HD1280x720p24
5.HD1920x1080i60
15.HD1920x1080p25
25.HD1280x720p23.98
6.HD1920x1080i59.94
16.HD1920x1080p24
26.3G1920x1080p60
7.HD1920x1080i50
17.HD1920x1080p23.98
27.3G1920x1080p59.94
8.HD1920x1080psf30
18.HD1280x720p60
28.3G1920x1080p50
9.HD1920x1080psf29.97
19.HD1280x720p59.94

10.HD1920x1080psf25
20.HD1280x720p50


2.Scaling/SD2SDASPECT(HasSUBMENUwithparameter)
ThisistheaspectratioconversionusedwhentheScalerisconvertingSDtoSD.
Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissubmenu.
Pressthe<and>buttonstomoveleftorrightthroughthe31aspectratioconversionslistedbelow
andtheBACKbuttontoleavethisSUBMENU.
1.ANAMORPHIC(INandOUThavesameaspect)
17.IN=14:9with4:3PB,OUT=16:9with4:3ZM
2.IN=16:9FS,OUT=14:9with16:9LB
18.IN=14:9with4:3PB,OUT=14:9with4:3ZM
3.IN=16:9FS,OUT=4:3with16:9LB
19.IN=14:9with16:9LB,OUT=4:3with16:9LB
4.IN=16:9FS,OUT=14:9with16:9CC
20.IN=14:9with16:9LB,OUT=14:9with16:9CC
5.IN=16:9FS,OUT=4:3with16:9CC
21.IN=14:9with16:9LB,OUT=4:3with16:9CC
6.IN=16:9with14:9PB,OUT=4:3with14:9LB
22.IN=4:3FS,OUT=16:9with4:3PB
7.IN=16:9with14:9PB,OUT=4:3with14:9CC
23.IN=4:3FS,OUT=14:9with4:3PB
8.IN=16:9with14:9PB,OUT=16:9with14:9ZM
24.IN=4:3FS,OUT=16:9with4:3ZM
9.IN=16:9with4:3PB,OUT=14:9with4:3PB
25.IN=4:3FS,OUT=14:9with4:3ZM
10.IN=16:9with4:3PB,OUT=16:9with4:3ZM
26.IN=4:3with16:9LB,OUT=14:9with16:9LB
11.IN=16:9with4:3PB,OUT=14:9with4:3ZM
27.IN=4:3with16:9LB,OUT=14:9with16:9CC
12.IN=14:9FS,OUT=16:9with14:9PB
28.IN=4:3with16:9LB,OUT=4:3with16:9CC
13.IN=14:9FS,OUT=4:3with14:9LB
29.IN=4:3with14:9LB,OUT=16:9with14:9PB
14.IN=14:9FS,OUT=4:3with14:9CC
30.IN=4:3with14:9LB,OUT=4:3with14:9CC
15.IN=14:9FS,OUT=16:9with14:9ZM
31.IN=4:3with14:9LB,OUT=16:9with14:9ZM
16.IN=14:9with4:3PB,OUT=16:9with4:3PB









