Wheels
The wheels are removed by opening out the handle (A) to the quick release mechanism and pulling
straight outwards. (Figure1).
Take care when removing the right-hand wheel. The battery holder and switch can easily start to
rotate if you do not hold one of them whilst loosening the wheel (Figure 2).
24" and 22” wheels
You can easily replace the e-move with regular 24" or 22” quick release drive wheels.
Open out the handle (A) and carefully pull out the wheel (Figure1).
For instructions on how to fold the actual wheelchair, please refer to the wheelchair instruction
manual enclosed with the delivery.
Decon Wheel AB Tel + 46 (0) 345-408 80
Landerydsvägen Fax +46 (0) 345-408 95
314 22 Hyltebruk www.decon.se
Sweden info@decon.se
