Dedal-NV 450 - Overview

4
12 5 8 3 4
6 2 11 1 9
7 10
1 – Body of the device
2 – Objective
3 – Eyepiece
4 – Rubber eye-cup
5 – Battery compartment
6 – Objective’s cover
7 – Windage/elevation adjustment mechanism
8 – On/Off/power alteration switch of the device and of the IR illuminator
9 – Adjustment switch of brightness of the centre of the reticle
10 – Objective focusing handle
11 – Rifle mount
12 – Built-in IR illuminator 75mW
Overview
