2 Installation
2.1 Installing the remote control
2.1.1. Choose a location
Choose a location in a "reference" room representative of the room
temperature to be taken into account if the remote control is used as a
room sensor.
Locations in the room that are not recommanded:
Enclosed, exposed to solar radiation, heated by a flue duct, exposed to
cold or hot air currents from air ducts, close to an open fireplace, a heat
source (television), behind a curtain.
2.1.2. Installing the remote control
1. Drill 2 holes with a Ø of 6 mm.
2. Put the plugs in place.
3. Tighten the 2 screws.
4. Connect either a 2-wire telephone cable or an electrical cable with
a cross-section of up to 2x1.5 mm² to the 2-pin connector. The wires
can be interchanged.
5. Installing the remote control.
