8
MAINTENANCE
Replacing the power supply cable
If the power supply cable should be replaced,
it is necessary
to use a cable
with a section
of 3x0.75mm
2
for the version
all gas and 3x1
mm
2
for the
version mixed,
type HO5VV-F or H05RR-F, complying with the
regulations in force.
The connection to the terminal board must be
effected as shown in fig.10:
brown cable L (phase)
blue cable N (neutral)
green-yellow cable (ground)
INSTRUCTIONS FOR THE INSTALLER
Fig.10
