Usingthedrawingsbelowasaguide,placethethreadedplateonthebraceassemblyintotheexistingholesinthe
vehiclepanel.Thebraceassemblyshouldbesnugagainstthebottomoftherockerpanelonthevehicle.Nowtighten
the3/8x11/4”hexheadboltonthebraceassemblyuntilsnugusinga9/16”wrench/orsocket.
Enutilisantlesschémasci-dessouscommeguide,placezleplatfiletésurlecroisillondanslestrousexistantsdansle
panneaudevéhicule.Lecroisillondevraitêtreconfortablecontrelebasdupanneaudeculbuteursurlevéhicule.Serrez
maintenantle3/8x11/4”;boulon principald'hexaducroisillonjusqu'àutiliserdouillettementun9/16”;clé/ouplot.
4
Brace
Assembly
Brace
Assembly
VehicleRocker
Panel
VehicleRocker
Panel
Brace
Assembly
Brace
Assembly
9/16“Wrench
orSocket
Brace
Assembly
3/8x11/4”Hex
HeadBolt
Brace
Assembly
Brace
Assembly
