Usingthebottomholeintheflangeonrockerpanelbracket(C)asaguide,drilla1/4”holethroughthe
vehiclerockerpanel.Securethebottomflangeonrockerpanelbracket(C)tothevehiclerockerpanel
using1/4x1”ribneckcarriageheadbolt(H),1/4”flatwasher(F),and1/4”hexnut(G)asshownbelow.
Tightenintoplaceusinga7/16”wrench/orsocket.
Enutilisantletrouinférieurdanslabridesurlaparenthèsedepanneaudeculbuteur(c)commeguide,
forezun1/4”;trouparlepanneaudeculbuteurdevéhicule.Fixezlabrideinférieuresurlaparenthèsede
panneaudeculbuteur(c)aupanneaudeculbuteurdevéhiculeenutilisant1/4x1”;boulondetêtede
chariotderibneck(h),1/4”;rondelleplate(f),et1/4”;écroud'hexa(G)commemontréci-dessous.Serrez
dansl'endroitenutilisantun7/16”;arrachez/ouplot.
7/16“Wrench
orSocket
Drillwitha
1/4”drillbit
Drillwitha
1/4”drillbit
C
VehicleRocker
Panel
H
VehicleRocker
Panel
C
F
G
