TECHNICAL INFORMATION
Item number 705200 (MultiCharger 1x12), 705400 (MarineCharger 1x12), 705600 (RescueCharger 1x12)
Mains Voltage [VAC] 230
Temperature Range [ºC] -35 +50
Charging Voltage* S1 [VDC] 14,4
Maintenance S2 [VDC] 13,5
Current Max. [A] 12
Battery Size Max. [Ah] 150
IP rating [IP] 44
Weight [kg] 1
Measure (H/W/D) [mm] 138x98x53
Acceptance EN60335-1, EN60335-2-29, EN55014-1, EN55014-2, EN61003-3/2
* Temperature-compensated approx 5,0 mV/
o
C/cell. Ref. 25
o
C.
