20
2. Steam installation
2.1 Security instructions for steam installation
- All work on the steam installation must only be performed by qualified technical
personnel. The customer is responsible for checking their qualifications.
- Please observe the local regulations governing the provision of ventilation ducts
with steam humidification.
2.2 Survey of steam installation
The following figure shows the steam installation to be provided by the customer.
Accessories available are indicated:
Steam distribution head, horizontal mounting Steam distribution head, vertical mounting
Mk4
Mk4
Mk4
Steam distribution head (accessory “81–...”
resp. “Z257” to “Z258”)
Steam hose (accessory “Z10”)
Condensate hose (108.3001)
Hose clamps
Support (20.4081)
