BI-WIRING
Bi-wiring in effect provides the midrange drivers and tweeter with separate
signal paths, improving their damping factor and reproducing recorded mate-
rial with greater clarity, depth and detail. Each Mythos ST-L Super Tower has
a set of Bi-wire (high level) 5-way binding posts, and an LFE input. Simply
run separate speaker wires to the low and high frequency drivers from a
single amplier.
Note: You must remove the jumper strips that connect the terminals before you
bi-wire your loudspeakers.
Connect one set of speaker wires to the upper terminals (tweeter) on
each speaker and one set of wires to the lower terminals (midrange/
subwoofer). Connect the other ends of both wire sets to the corresponding
amplier outputs.
Important Note: Both speakers must be connected in the same way (in correct
polarity) to their own channel of the amplier. If you experience a great lack of
bass, it’s likely that one speaker is out of polarity with the other.
AMPLIFIER
LEFT CHANNEL RIGHT CHANNEL
BI-WIRING
