18
Denitive Technology
11433 Cronridge Dr.
Owings Mills, MD 21117
EN
LED INDICATORS
There is a single Power LED on the back panel of
each loudspeaker. There are 15 LEDs on the front
panel below the Denitive Technology logo that
light to indicate any change you make in volume
levels or power status.
Remote Control LED Indicates
Power On LED on rear panel shines red.
White LED’s turn on sequentially from the middle
to the outside then show the base trim value and
end at blue LED center.
Power Off All LEDs on front of tower shine, then turn off
sequentially.
Volume Levels
(Stereo Bass, Left & Right Bass)
On front of tower: Indicated by +/-7 white LEDs
to the left and right of the blue center LED.
Low Level Mode On: Center Blue LED turns to red and dims
Off: Center red LED turns blue and trim value
shown on white LEDs. Hold and then fade to dim
Blue LED
Mute On: Center blue LED turns red and then fades in
and out until mute condition is terminated
Off: Center red LED turns blue, trim value is
shown on white LED’s, hold and then fade to dim
blue LED
Rear Panel Controls LED Indicates
Sub Level +/-
Indicated by +/
– 7 white LEDs on front panel.
Subwoofer Gain
–10, 0, +10 indicated by 3 blue LEDs
Amplier Power On/Off Indicated by red LED
VOLUME LEVELS UPVOLUME LEVELS DOWN
