Defy 600 EMBW - Eye level installation; Installation Procedure; Hob installation; Dimensions and Placement

3
Eye level installation
models 600 STE, 600 EMBW,
•
Insert the oven into the cupboard.
•
Open the door to expose the fixing holes in the side trims.
•
Secure the oven by 4 countersunk screws (fasteners are not supplied ).
(A)
Aperture
Typical section showing
ventilation requirements
565
(B)
A
bove floo
r
level
Floor
60
+
_
3
0
+
_
3
0
+
_
3
0
+
_
3
0
Dimension (A)
Dimension (B)
590mm
900mm
840mm
650mm
600STE
600 SMW
600 EMBW
Hob installation
600 SOLID PLATE NCP AND 600 CERAN
570
80
Worktop front
480
+
_
3
0
+
_
3
0
+
_
3
0
( 40 )
MODELS
600 SOLID PLATE
NO CONTROL PANEL
600 CERAN
NO CONTROL PANEL
