Draining the water tank. (Continued)
• Drain the tank and clean the funnel of
any lint
• Slide the empty tank back in it’s housing.
Never remove the water tank whilst
the dryer is operating.
Condensed water is not fit for drinking
Cleaning the condenser
Hot and humid air is cooled using ambient
air. Humid air circulating in the dryer is
cooled, condensed and pumped into the
tank.
Clean the condenser once a month or after
every 30 drying cycles.
Wait until the dryer has cooled down.
1. Open the front flap
2. Unlock the 2 condenser locks
3. Pull the condenser out
4. Clean the condenser with pressurised
water and wait until all the water
drains off. Fit the condenser back in
it’s housing
5. Replace the condenser back into its
housing. Fasten the 2 Condenser
locks and ensure they are seated
correctly.
6. Close the front flap
1
2
3
4
5
6
