Page 8
Preparation before washing
1. Adjust the feet to level the machine.
Unscrew the 4 screws of part A and sleeve
part A horizontally over the opening of the
water tap (Opening of water tap must be flat
and smooth. Flatten with a file if it is not flat)
and push upward ensuring the rubber is
centrally seated in the tap opening. Tighten
the 4 screws sequentially, thereafter tighten
screw on part B.
The connection socket consists of 2 parts A
& B. Before installation these parts should
be partially unscrewed by approximately 5
mm, or can be disconnected. If the bore of
the water tap is larger, remove the plastic
spacer ring from part A.
To Connect:
Push down the slide jacket of the speedy
connector (the 4 small balls must be
exposed) and insert it into the connection
socket and then push upwards and then
release. Open the water tap for water flow.
To Separate:
Close the water tap. Push the slide jacket of
the speedy connecter down and then pull out
the speedy connector.
Fasten other end of water inlet hose onto
water inlet valve. (with rubber seal ring
inside).
Plastic
spacer ring
Note: When tightening the
clamping nut, do so evenly and do
not use force or twist the water inlet
valve as the water inlet valve joint
may break.
Adjustable foot
