Page 5
Securing the water tube.
Fasten the tube using the fastener A.
Check that the tube is not twisted or kinked.
Tighten all the joints, open the tap and ensure that there are
no leaks.
Connect the water tube to the refrigerator
Remove the rear cover at the bottom back of the refrigera-
tor.
Insert the fastening ring into the tube following the direction
of the nut.
Insert the tube into the top of the water valve which is lo-
cated to the right of the compressor, and tighten the nut.
Replace the rear cover, ensuring that the tube is located in
groove between the refrigerator and the rear cover.
Using the filter for the first time.
Open the tap and check the clarity of the water after it has
passed through the filter.
Some impurities lodged in the filter during the manufactur-
ing process may be visible.
Run the water until all the impurities have been removed.
Complete the installation
Plug in and switch on the electricity.
Press WATER on the control panel for 2 to 3 minutes to
remove any air bubbles and water used during leak testing.
Do a final leak and installation check.
Thereafter, do not move the refrigerator from its installed
position.
Securing the filter.
Fasten the filter holder in an easily accessible position ( i.e.
the left back of the refrigerator using double sided adhesive
tape or to the wall using a screw and wall plug) and clamp
the filter into the holder.
