15
2
1
3
4
34 cm
cm
14 cm
Installation
WIRING - ELECTRIC VERSION
OPTION
230 V Power supply
The electric control box must be fitted in a dry room.
et CEI 60364
(Last applicable version) ask your electrician for advice or contact your electricity provider.
Upstream from the control box a suitably sized circuit breaker with a 30 mA ground fault device must be
provided.
(U1000RO2V in a sheath) compliant with applicable standards
Wiring - refer to the manual supplied with the product
