Installation
WI-KEY INSTALLING THE CONTROL BOX
- It must be located in a place from which it is possible to check
that no one enters the pool during the manoeuvre.
- It is mandatory to install the locking «strip».
- Before fixing the control box, check that the emitter is
communicating with the receiver.
”if the motor does not run => check the power supply polarity
The support must be attached to a fixed support
Closing
Opening
Stops the current action
Keyboard lock
red / green flashing = emitter locked
Emitter unlocking procedure see «page 27»
The emitter must be located outside volume 0.
The distance between the emitter and the receiver must not exceed:
