Installation
The position of the fastener kits on
the cover is indicated on the drawings
shipped with the slats.
LOCKING KITS
The Quick-lock fastener system cannot be used on cut off
corners and curves, except at the end of Roman steps.
Without steps
With Roman
steps
kit at the end
of the steps
Roman
2 kits at max.
edge
kit at max.
the edge
1 kit centred if < 1 m
2 kits if > 2 m
* X must never exceed 2 m
With side
steps
With
straight
or trapezoidal
steps
Positioning rules
All changes to the positioning of the kits must comply with the rules given below.
For other cases please contact us.
