DEL TIXIT - Fastener Kit Installation

23
Ø8
5 cm
mini
For concrete and panel pools
PUSH-LOCK INSTALLATION
For concrete and panel pools

water level
Acceptable limit of
level variation

Hang mounted version
Insert mounted model
Installation
A water level regulator is mandatory


recommended
5 cm
mini


For concrete and concrete block pools, as well as pools with
wall thickness greater than or equal to 8 mm
Surface mounted model
60 mm “minimum”
Once the resistance
point has been
reached stop screwing,
this would deteriorate
the fixture quality.
Concrete
After reaching the
resistance point, make
3 more turns of the
screwdriver
to finish tightening.
Concrete block
Plug
Washer
Washer

Ø8
VBA TF Torx
stainless steel A4 Ø6

Screw cap
Hollow white
Ø16 washer
Inserted
part
Screw cap
Hang mount support
Ø12 Nylon
plug
Stainless steel nut
A4 M10
Cale
13 mm
VBA TF Torx
stainless steel A4

Hollow white
Ø16 washer
INOX
M6 washer
water level
Acceptable limit of
level variation
recommended
water level
Acceptable limit of
level variation
recommended
Universal 8 x 40 plug
VBA TF Torx stainless

screw
Hollow white Ø16
washer
Screw cap
