CHAPTER 11: POWER SUPPLY
Disconnect the DC wire harness and the AC power cable from the power 5.
supply.
Loosen the four captive screws that secure the power supply to the back of 6.
the chassis.
Slide the power supply through the back of the chassis.7.
1
2
1 power supply 2 captive screws (4)
Remove the four screws that secure the power supply to the bezel.8.
Remove the bezel from the power supply.9.
2
3
1
1 bezel 2 power supply
3 screws (4)
