085
085
/
CHAPTER 17: ACTIVE-VENTING ASSEMBLY
Place the chassis in an upright position.8.
Remove the right top-panel.9.
1
1 right top-panel
Remove the top lighting-board (see “Removing the Top Lighting-Board” on 6.
page 76).
Remove the ten screws that secure the active-venting assembly to the 7.
chassis.
1
1 screws (10)
