5 USB 3.1 Gen 2 Type-C port
Connect peripherals, such as external storage devices and printers.
Provides data transfer speeds up to 10 Gbps.
NOTE: This port does not support video/audio streaming or
power delivery.
6 USB 3.1 Gen 2 port
Connect peripherals, such as external storage devices and printers.
Provides data transfer speeds up to 10 Gbps.
7 Side L/R surround port
Connect audio-output devices such as speakers and amplifiers. In a 7.1
speaker channel setup, connect the side-left and side-right speakers.
8 Microphone port
Connect an external microphone to provide sound input.
9 Front L/R surround line-out port
Connect audio-output devices such as speakers and amplifiers. In a 2.1
speaker channel setup, connect the left and right speakers. In a 5.1 or a 7.1
speaker channel setup, connect the front-left and front-right speakers.
10 Line-in port
Connect recording or playback devices such as a microphone or CD player.
11 Center/subwoofer LFE surround port
Connect the center speaker or the subwoofer.
NOTE: For more information about the speaker setup, refer the
documentation that shipped with the speakers.
12 Rear L/R surround port
Connect audio-output devices such as speakers and amplifiers. In a 5.1 or
a 7.1 speaker channel setup, connect the rear-left and rear-right speakers.
13 USB 3.1 Gen 1 ports (3)
Connect peripherals such as external storage devices and printers.
Provides data transfer speeds up to 5 Gbps.
14 Network port (with lights)
Connect an Ethernet (RJ45) cable from a router or a broadband modem for
network or Internet access.
16
