Dell B3465DNF User Manual

Installing hardware options
Order of installation
CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more
trained personnel to lift it safely.
CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or
memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord
from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
CAUTION—TIPPING HAZARD: Floor‑mounted configurations require additional furniture for stability. You must
use either a printer stand or printer base if you are using a high‑capacity tray and an input option, or more than
one input option. If you purchased a multifunction printer (MFP) that scans, copies, and faxes, you may need
additional furniture. For more information, contact the place where you purchased the printer.
Install the printer and any hardware options you have purchased in the following order:
• Printer stand
• Optional 550‑sheet tray
• Printer
For more information on installing a printer stand, optional 550‑sheet tray, or spacer, see the setup sheet that came
with the option.
Installing optional trays
CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more
trained personnel to lift it safely.
CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or
memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord
from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
CAUTION—TIPPING HAZARD: Floor-mounted configurations require additional furniture for stability. You must
use either a printer stand or printer base if you are using a high-capacity tray and an input option, or more than
one input option. If you purchased a multifunction printer (MFP) that scans, copies, and faxes, you may need
additional furniture. For more information, contact the place where you purchased the printer.
1 Turn off the printer using the power switch, and then unplug the power cord from the electrical outlet.
2
1
2
Additional printer setup 43

Dell B3465DNF Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2500 - 15000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5c, PCL 5e, PCL XL, PostScript 3
Wi-Fi	-
Memory type	DDR3
Maximum internal memory	3072 MB
Total input capacity	550 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Custom media width	70 - 127 mm
Maximum print size	216 x 356 mm
Duplex media weight	216 - 356 g/m²
Paper tray media types	Bond paper, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Pro, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional
Power consumption (printing)	- W
Package depth	573 mm
Package width	599 mm
Package height	673 mm
Package weight	28000 g
Display	LCD

Weight and Dimensions

Depth	479 mm
Width	489 mm
Height	561 mm
