80 Adding Parts
www.dell.com | support.dell.com
7 Pull the two front-panel tabs towards you, and then push out the front-panel insert.
8 Ensure that the jumper setting on the new drive is set for "cable select" (see the
documentation that came with the drive for information).
9 Remove two extra alignment screws, shown in the illustration on page 81, from the
front of the computer and insert them into the drive.
tabs (2)
insert
drive
alignment screws (2)
