Appendix 91
Memory
Architecture DDR SDRAM
Memory connectors two
Memory capacities 128-, 256-, and 512-MB non-ECC DDR
SDRAM
Minimum memory 128 MB
Maximum memory 1 GB
Memory type DDR (non-ECC)
BIOS address F8000h
Drives
Externally accessible two 5.25-inch bays
two 3.5-inch bays
Internally accessible two bays for 1-inch–high IDE hard drives
Available devices ATA-66 or ATA-100 Ultra DMA hard drive,
CD drive, Zip drive, DVD drive, DVD+RW
drive, and CD-RW drive
Ports and Connectors
Externally accessible:
Serial 9-pin connector; 16550C-compatible
Parallel 25-hole connector (bidirectional)
Video 15-hole connector
Keyboard 6-pin mini-DIN connector or USB connector
Mouse 6-pin mini-DIN connector or USB connector
USB two front-panel and two back-panel
USB–compliant connectors
Headphone front-panel miniature connector
Audio
1
three miniature connectors for line-in, line-
out, and microphone
1
Present only on computers with integrated audio capabilities.
