Appendix 93
Physical
Height x Width x Depth 42.5 x 18.1 x 44.7 cm
(16.7 x 7.1 x 17.6 inches)
Weight 12.7 kg (28 lb)
Environmental
Temperature:
Operating 10° to 35°C (50° to 95°F)
3
Storage –40° to 65°C (–40° to 149°F)
Relative humidity 20% to 80% (noncondensing)
Maximum vibration:
Operating 0.25 G at 3 to 200 Hz at 1/2 octave/min
Storage 0.5 G at 3 to 200 Hz at 1/2 octave/min
Maximum shock:
Operating bottom half-sine pulse with a change in
velocity of 50.8 cm/sec (20 inches/sec)
Storage 23-G faired-square wave with a velocity
change of 508 cm/sec (200 inches/sec)
Altitude:
Operating –15.2 to 3048 m (–50 to 10,000 ft)
3
Storage –15.2 to 10,670 m (–50 to 35,000 ft)
3
At 35°C (95°F), the maximum operating altitude is 914 m (3000 ft).
