Dell E176FPc User Manual

Dell E176FPc
68
R915 61L0805220 CHIP 22 OHM 5% 0805 1/8
R916 61L0805221 CHIPR 220 OHM +-5% 1/8W
R917 61L0805103 CHIPR 10K OHM +-5% 1/8W
R919 61L0805203 CHIPR 20KOHM +-5% 1/8W
R924 61L0805102 CHIPR 1K OHM +-5% 1/8W
R925 61L1206000 RST SM 1206 JUMP MAX 0R
R929 61L0805330 2F CHIP 33KOHM 1/8W 1%
R930 61L0805360 1F CHIP 3.6KOHM 1/8W 1%
R931 61L0805102 CHIPR 1K OHM +-5% 1/8W
R932 61L0805102 CHIPR 1K OHM +-5% 1/8W
R933 61L0805240 1F CHIPR 2.4KOHM +-1% 1/8W
ZD201 93G 39S 8 T RLZ11B LLDS
ZD901 93G 39S 44 T RLZ18B LLDS
ZD902 93G 39S 25 T RLZ5.1B LLDS
ZD903 93G 39S 38 T PTZ 9.1B
ZD904 93G 39S 40 T RLZ 13B LLDS
ZD905 93G 39S 25 T RLZ5.1B LLDS
715G1492 1 FR PCB
C209 67G 305330 7T
33UF 105
C904 6G 31502 1.5MM RIVET
C905 65G 2K152 1T6921 1.5NF/2KV Y5P +-10%
C906 67G 2151014KT 100UF
C909 67G 3054704KT 47UF
C921 65G517K102 5T 1000PF 10% Y5P 500V
C922 65G517K102 5T 1000PF 10% Y5P 500V
CN901 6G 31500 EYELET
D202 93G 64 1152T 1N4148
D203 93G 64 1152T 1N4148
D204 93G 64 1152T 1N4148
D205 93G 64 1152T 1N4148
D206 93G 64 1152T 1N4148
D207 93G 64 1152T 1N4148
D208 93G 64 1152T 1N4148
D209 93G 64 1152T 1N4148
D902 93G1020 752T UF4003
F901 84G 56 1 FUSE 2A 250V WICKMANN
IC903 56G 158 12 KIA431A-AT/P TO-92
J914 71G 55 9 T FERRITE BEAD
L902 6G 31502 1.5MM RIVET
