17" LCD Color Monitor
Dell
E177FPc
45
White sc
reen
Check R725 whether there is a volt
age of 3.3V
, when
the power is on
If Q704,
Q706 is broken or
CN101
abnormally
soldered
Replace Q704, Q706 or re-sol
der CN101
Replace P
ANEL
or FPC cable
Replace U401
Check
X401, C427,
C428
NG
NG
X401 oscillating waveform is
normal
OK
OK
NG
OK
44
46
Table of Contents
Default Chapter
1
Table of Contents
1
Revision List
2
ECN History
3
Important Safety Notice
4
1 Monitor Specifications
5
2 LCD Monitor Description
6
3 Operation Instructions
7
General Instructions
7
Control Buttons
7
On Screen Menu/Display (OSD)
8
Adjusting the Picture
9
4 Input/Output Specification
14
Input Signal Connector
14
Factory Preset Display Modes
14
Power Supply Requirements
15
Panel Specification
16
Definition of Pixel
19
5 Block Diagram
23
Monitor Exploded View
23
Software Flow Chart
24
Electrical Block Diagram
26
6 Schematic Diagram
28
Main Board
28
Power Board
33
7 PCB Layout
35
Main Board
35
Power Board
37
Key Board
39
8 Maintainability
40
Equipments and Tools Requirement
40
Trouble Shooting
41
9 White-Balance, Luminance Adjustment
49
10 ISP Instruction
51
11 Check List
55
12 BOM List
58
13 Different Parts List
93
