17" LCD Color Monitor
Dell
E177FPc
47
OSD is unstable or not working
NG
If pin1 of IC201 has saw tooth wave
No backlight
Connect PIN15 of IC201 to the
ground If the picture is normal
Check C207 and IC2
01
If Q206/Q207 waveforms are normal
Check ZD201/IC201 etc
Replace Q206/Q207
Check C209, flyback circuit
and lamp
OK
NG
NG
OK
OK
NG
46
48
Table of Contents
Default Chapter
1
Table of Contents
1
Revision List
2
ECN History
3
Important Safety Notice
4
1 Monitor Specifications
5
2 LCD Monitor Description
6
3 Operation Instructions
7
General Instructions
7
Control Buttons
7
On Screen Menu/Display (OSD)
8
Adjusting the Picture
9
4 Input/Output Specification
14
Input Signal Connector
14
Factory Preset Display Modes
14
Power Supply Requirements
15
Panel Specification
16
Definition of Pixel
19
5 Block Diagram
23
Monitor Exploded View
23
Software Flow Chart
24
Electrical Block Diagram
26
6 Schematic Diagram
28
Main Board
28
Power Board
33
7 PCB Layout
35
Main Board
35
Power Board
37
Key Board
39
8 Maintainability
40
Equipments and Tools Requirement
40
Trouble Shooting
41
9 White-Balance, Luminance Adjustment
49
10 ISP Instruction
51
11 Check List
55
12 BOM List
58
13 Different Parts List
93
