Dell E177FPc User Manual

17" LCD Color Monitor Dell E177FPc
60
CN701 033G8027 12 WAFER 2*6P 2.0MM R/A
CN101 033G8043 24 H CONNECTER
040G 457624 1B LABEL-CPU
040G 45762412B CBPC LABEL
C702 067G405D4797PV ELCAP 4.7UF M 50V
CN405 088G 35315F H D-SUB 15PIN
X401 093G 22 53 CRYSTAL 14.318MHzHC-49US
AIC780KC4DLP MAIN BOARD
052G6022 20 SMALL TAPE
CN1 089G176F 8513 FFC CABLE HF
012G6078 1 PORON INVERTER
CN201 033G8021 2D AC CONN.2P R/A 87210-0236 DIP BY
CN202 033G8021 2D AC CONN.2P R/A 87210-0236 DIP BY
CN203 033G8021 2D AC CONN.2P R/A 87210-0236 DIP BY
CN204 033G8021 2D AC CONN.2P R/A 87210-0236 DIP BY
CN901 033G8029 3A H B2P3S-VH
040G 45762420A LABEL 25x6mm
P051 051G 6 4503 RTV
052G6025 11935 MYLAR FOR PANEL
IC902 056G 139 3A PC123Y22FZOF
Q207 057G 761 7 KTD1691P
Q206 057G 761 7 KTD1691P
NR901 061G 58080 WT 8 OHM NCT
R908 061G152M10458G6267 100K OHM 5% 2W
R918 061G152M398 64 0.39 OHM 2W
C903 063G 107474 HS 0.47UF +-20% 275VAC
C221 063G211J334 AB 0.33UF 5% 160V R75 BY ARCO
C211 065G 3J1206ET 12PF 5% SL 3KV TDK
C214 065G 3J1206ET 12PF 5% SL 3KV TDK
C212 065G 3J2206ET 22PF 5% SL 3KV TDK
C213 065G 3J2706ET 27PFJ 3KV SL
C902 065G305M2222BP 2200PF +-20%
C901 065G305M2222BP 2200PF +-20%
C900 065G306M4722BP 4700PF +-20% 400VAC
C931 067G215L102 4R LOW E.S.R 1000UF +/-20% 25V
C924 067G215L102 4R LOW E.S.R 1000UF +/-20% 25V
C923 067G215L102 4R LOW E.S.R 1000UF +/-20% 25V
C925 067G215L471 4R OW E.S.R 470UF +/-20% 25V
C203 067G215L471 4R OW E.S.R 470UF +/-20% 25V
