20 │ Setting up the monitor
To remove the VESA cover:
Press the dimple on the VESA cover to release it from the back of the display.
Wall Mounting (Optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible base mounting kit.
1. Place the monitor panel on a soft cloth or cushion on a stable flat table.
2. Remove the stand.
3. Use a screwdriver to remove the four screws securing the plastic cover.
4. Attach the mounting bracket from the wall mounting kit to the LCD.
5. Mount the LCD on the wall by following the instructions that came with the base
mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall-mount bracket with
minimum weight/load bearing capacity of 9.04 kg (19.93 lb) for E2223HV.

Dell E2223HV Specifications

General

Panel type	VA
Pixel pitch	0.249 x 0.249 mm
Screen shape	Flat
Pixel density	103 ppi
Response time	12 ms
Backlight type	LED
Display diagonal	21.45 \
Heat dissipation	64.79 BTU/h
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	8 ms
Horizontal scan range	30 - 83 kHz
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	54.48 cm
Display brightness (typical)	250 cd/m²
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, RoHS, TCO
DisplayPorts quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	19 W
Power consumption (off)	0.3 W
Power consumption (typical)	12.13 W
Package weight	4010 g
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Office
Cables included	AC, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (side)	12.8 mm
Depth (with stand)	171 mm
Width (with stand)	504.26 mm
Height (with stand)	384.17 mm
Weight (with stand)	2900 g
Bezel width (bottom)	16.9 mm
Depth (without stand)	49.64 mm
Height (without stand)	295.38 mm
Weight (without stand)	2260 g
