Table 20. Dimension details
appliance Xa Xb Y Za (with
bezel)
Za (w/o
bezel)
Zb
*
Zc
10 x 2.5 inches
482.0 mm
(18.9 inches)
434.0 mm
(17.08 inches)
42.8 mm
(1.68
inches)
35.84 mm
(1.41 inches)
22.0 mm
(0.87
inches)
733.82 mm
(29.61 inches)
772.67 mm
(30.42
inches)
Chassis weight
Table 21. Chassis weight
System Maximum weight (with all hard drives/SSDs)
VxRail E560 Series 21.9 kg
(48.28 lbs)
Processor specifications
The VxRail E560, E560F, and E560N appliance supports up to two Intel Xeon Processor Scalable Family processors.
PSU specifications
The VxRail E560, E560F, and E560N appliance supports two AC or DC power supply units (PSUs).
Table 22. PSU specifications
PSU Class Heat dissipation
(maximum)
Frequency Voltage
1100 W DC Gold 4416 BTU/hr 50/60 Hz –(48–60) V DC
1100 W Mixed
Mode HVDC (for
China and Japan
only)
Platinum 4100 BTU/hr 50/60 Hz 100–240 V AC and 200–380 V DC
1100 W AC Platinum 4100 BTU/hr 50/60 Hz 100–240 V AC, autoranging
NOTE: If an appliance with 1100 W AC or HVDC PSU operates from 100 to 120V, the power rating per PSU is derated to
1050 W.
NOTE: Heat dissipation is calculated using the PSU wattage rating.
NOTE: This appliance is also designed to connect to the IT power systems with a phase to phase voltage not exceeding
240 V.
Battery specifications
The VxRail E560, E560F, and E560N appliance supports CR 2032 3.0-V lithium coin cell battery.
Expansion bus specifications
The VxRail E560, E560F, and E560N appliance supports PCI express (PCIe) generation 3 expansion cards, which must be
available on the system board by using expansion card risers.
22
Technical specifications
