Dell G2210 - Physical Identification

Back View

Side View

Front View
Front panel controls
Label
Description
1
Ambient light Sensor Lens
2
Shortcut Key 1 / Up button
3
Shortcut Key 2 / Down button
4
OSD menu button / OK button
5
Back / Exit button
6
Power button (with power light indicator)
Back view
Back view with monitor stand
Label
Description/Use
1
VESA mounting holes (100 mm)
(behind attached VESA plate)
Use to mount the monitor.
2
Barcode serial number label
Refer to this label if you need to contact Dell for technical support.
3
Security lock slot
Use a security lock with the slot to help secure your monitor.
4
Dell Soundbar mounting brackets
Attach the optional Dell Soundbar.
5
Stand removal button
Press to release the stand.
6
Regulatory rating label
Lists the regulatory approvals.
7
Cable management slot
Use to organize cables by placing them through the slot.
