Camera
Table 14. Camera specifications
Resolution
● Still image: 0.92 megapixel
● Video: 1280 x 720 (HD) at 30 fps (maximum)
Diagonal viewing angle 74 degrees
Table 15. Camera specifications
Resolution Camera
● Still Image: 0.92 megapixel
● Video: 1280x720 (HD) at 30 fps (maximum)
Infrared camera
640 x 480 (VGA)
Diagonal viewing angle Camera
74 degrees
Infrared camera
60 degrees
Touch pad
Table 16. Touch pad
Resolution
● Horizontal: 1260
● Vertical: 960
Dimensions
● Height: 65 mm (2.56 in)
● Width: 105 mm (4.13 in)
Power adapter
Table 17. Power adapter specifications
Type 45 W
Diameter (connector) 4.5 mm
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Input current (maximum) 1.30 A
Output current (continuous) 2.31 A
Temperature range
● Operating: 0°C to 40°C (32°F to 104°F)
● Storage: –40°C to 70°C (–40°F to 158°F)
Battery
Table 18. Battery specifications
Type 3-cell “smart” lithium-ion (42 WHr)
Specifications 15
