Dell Inspiron 15-7559 User Manual

Replacing the camera
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Procedure
1 Connect the camera cable to the camera.
2 Adhere the tape that secures the camera cable to the camera.
3 Turn the camera over and align the camera to the alignment posts on the
display back-cover and snap the camera in place.
Post-requisites
1 Replace the display panel.
2 Replace the display bezel.
3 Replace the display assembly.
4 Replace the fans.
5 Follow the procedure from step 2 to step 6 in “Replacing the palm rest”.
6 Replace the keyboard.
7 Follow the procedure from step 4 to step 6 in “Replacing the hard drive”.
8 Replace the base cover.
9 Replace the battery.
95

Dell Inspiron 15-7559 Specifications

General

Processor	Intel Core i5-6300HQ / i7-6700HQ
Graphics	NVIDIA GeForce GTX 960M (4GB GDDR5)
Operating System	Windows 10 Home
Weight	5.67 lbs (2.57 kg)
RAM	8GB DDR3L
Storage	1TB HDD + 8GB SSD
Battery	6-cell 74Whr Lithium-Ion
Dimensions	383 x 265 x 24.9 mm
Ports	3 x USB 3.0, HDMI, Headphone/Microphone Combo, SD Card Reader, Ethernet
Wireless	802.11ac + Bluetooth 4.0
Webcam	720p
