4. Turn the system board over.
5. Align the connectors on the system board with the slots on the computer base.
6. Use the alignment posts on the computer base to correctly place the system board.
7. Replace the six screws that secure the system board to the computer base.
8. Slide the optical drive board cable into the connector on the system board, and press down on the connector latch to secure the cable.
9. Slide the USB/audio cable into the connector on the system board, and press down on the connector latch to secure the cable.
10. Connect the following cables to their connectors on the system board:
l speaker cable
l display cable
l AC adapter connector cable
l microphone cable
11. Replace the processor fan (see Replacing the Processor Fan).
12. Replace the Bluetooth card (see Replacing the Bluetooth Card).
13. Replace the palm rest (see Replacing the Palm Rest).
14. Replace the keyboard (see Replacing the Keyboard).
15. Replace the power button panel (see Replacing the Power Button Panel).
16. Replace the hard drive (see Replacing the Hard Drive).
17. Replace the Mini-Card (see Replacing the Mini-Card).
18. Replace the memory module(s) (see Replacing the Memory Module(s)).
19. Replace the coin-cell battery (see Replacing the Coin-Cell Battery).
20. Replace the module cover (see Replacing the Module Cover).
21. Replace the optical drive (see Replacing the Optical Drive).
22. Replace the battery (see Replacing the Battery).
23. Turn on the computer.
24. Enter the service tag (see Entering the Service Tag in the BIOS).
Entering the Service Tag in the BIOS
1. Ensure that the AC adapter is plugged in and that the main battery is installed properly.
2. Turn on the computer.
3. Press <F2> during POST to enter the system setup program.
4. Navigate to the security tab and enter the service tag in the Set Service Tag field.
