Replacing the display back-cover and
antenna assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working
inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
Place the display back-cover and antenna assembly on a clean and flat surface.
Post-requisites
1. Replace the display cable.
2. Replace the display hinges.
3. Replace the display panel.
4. Replace the camera.
5. Replace the display bezel.
6. Replace the display assembly.
7. Replace the wireless card.
8. Replace the base cover.
9. Replace the optical drive.
57
102 Replacing the display back-cover and antenna assembly

Dell Inspiron 17 5000 Specifications

General

Display Size	17.3 inch
Processor	Intel Core i5/i7
RAM	8GB/16GB DDR4
Storage	Up to 1TB NVMe SSD
Operating System	Windows 10
Ports	USB 3.1, USB 2.0, HDMI, SD card reader, headphone/microphone jack
Wireless	Bluetooth
Battery	3-cell or 4-cell lithium-ion
