28 | Optical Drive
3 Carefully pry the optical-drive bezel and remove it from the
optical-drive assembly.
4 Remove the screws that secure the optical-drive bracket to the
optical drive.
5 Remove the optical-drive bracket.
1 optical-drive bezel 2 optical drive
3 optical-drive bracket 4 screws (2)
1
2
4
3
