Dell Inspiron 3558 User Manual

Removing the display
assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Prerequisites
1 Remove the battery.
2 Remove the base panel.
3 Follow the procedure from step 1 to step 3 in “Removing the hard drive”.
4 Remove the memory modules.
5 Remove the wireless card.
6 Remove the keyboard.
7 Follow the procedure from step 1 to step 8 in “Removing the palm rest”.
8 Follow the procedure from step 1 to step 8 in “Removing the system
board”.
Procedure
1 Turn the computer over and open the display as far as possible.
2 Note the antenna cable routing and remove the antenna cables from its
routing guides on the computer base.
70

Dell Inspiron 3558 Specifications

General

Optical Drive	Tray load DVD Drive (Reads and Writes to DVD/CD)
Processor	Intel Core i5-5200U
RAM	4GB DDR3L
Storage	1TB HDD
Display	15.6-inch HD (1366 x 768)
Graphics	Intel HD Graphics 5500
Operating System	Windows 8.1
Battery	4-cell, 40 WHr
Connectivity	Bluetooth 4.0
Ports	1 x USB 3.0, 2 x USB 2.0, HDMI, RJ-45
Dimensions	380 mm (14.96")
