AC Adapter
Input voltage 100–240 VAC
Input current (maximum) 1.5 A
Input frequency 50–60 Hz
Output power 65 W or 90 W
Output current
65 W
4.34 A (maximum at 4-second pulse)
3.34 A (continuous)
90 W
5.62 A (maximum at 4-second pulse)
4.62 A (continuous)
Output voltage 19.5 +/– 1.0 VDC
Dimensions
Width
65 W
66.00 mm (2.60 inches)
90 W
70.00 mm (2.75 inches)
Height
65 W
16.00 mm (0.63 inches)
90 W
16.00 mm (0.63 inches)
Depth
65 W
127.00 mm (5.00 inches)
90 W
147.00 mm (5.78 inches)
Temperature range
Operating
0 °C to 40 °C (32 °F to 104°F)
Storage
–40 °C to 70 °C (–40 °F to 158 °F)
Physical
Front height 26.50 mm (1.04 inches)
Back height 30.50 mm (1.20 inches)
Width 323 mm (12.72 inches)
Depth 215 mm (8.47 inches)
Weight 1.63 kg–1.95 kg (3.60 lb–4.30 lb)
Environmental
Temperature range
Operating
0 °C to 35 °C (32 °F to 95 °F)
Storage
–40 °C to 70 °C (–40 °F to 158 °F)
Relative humidity (maximum)
Operating
10 % – 90 % (noncondensing)
Storage
5 % – 95 % (noncondensing)
Altitude (maximum)
Operating
–15.2 m to 3048 m (–50 ft to 10,000 ft)
Storage
–15.2 m to 10,668 m (–50 ft to 35,000 ft)
7JR5Tam1.fm Page 5 Monday, June 14, 2010 4:46 PM
