Dell Latitude E6330 - Page 2

Discover leading-edge laptops at Dell.com/Latitude
1. Dell Latitude laptops are brominated flame retardant free (BFR-free) and polyvinyl chloride free (PVC-free); meeting the definition of BFR-/PVC-free as set forth in the iNEMI Position
Statement on the ‘Definition of Low-Halogen Electronics (BFR-/CFR-/PVC-free)’. Plastic parts contain less than 1,000 ppm (0.1%) of bromine (if the Br source is from BFRs) and less
than 1,000 ppm (0.1%) of chlorine (if the Cl source is from CFRs or PVC or PVC copolymers). All printed circuit board (PCB) and substrate laminates contain bromine/chlorine total
less than 1,500 ppm (0.15%) with a maximum chlorine of 900 ppm (0.09%) and maximum bromine being 900 ppm (0.09%).
2. WiFi enabled connection required. System must be on or in sleep mode with application running to update.
3. Oering available in select countries.
4. Not available in China or Russia.
5. Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.
6. Only available in emerging markets.
7. A 64-bit operating system is required to support 4GB or more of system memory.
8. Significant system memory may be used to support graphics, depending on system memory size and other factors
9. GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
10. Limited Hardware Warranty: For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty.
11. Mobile Broadband: Subject to wireless provider’s broadband subscription and coverage area; additional charges apply.
12. Based on preliminary Dell lab testing. Weights vary depending on configuration and manufacturing variability.
Feature Technical Specification
Processor Options Intel® Core™ i3, i5 and i7 processors up to i7-35x0M
Operating System Options Genuine Windows
®
7 Home Basic
6
Genuine Windows
®
7 Home Premium
Genuine Windows
®
7 Professional
Genuine Windows
®
7 Ultimate
Linux Ubuntu 11.10
Memory
7
Options DDR3 SDRAM (1600MHz ) 2 slots supporting 2G, 4GB, 8GB
7
DIMMs
Chipset and Intel Responsiveness Technologies Mobile Intel
®
QM77 Express Chipset
Optional Intel Rapid Start Technology (SSD is required)
Optional Intel Smart Connect Technology (SSD and Intel WLAN are required)
Graphics
8
Options Intel
®
HD Graphics 4000 (for Intel Core i3/i5/i7 3xxxM processors)
Intel
®
HD Graphics 3000 (for Intel Core i3 processors)
Display 13.3” HD (1366x768) Anti-Glare LED
Storage
9
Options 7200 rpm SATA up to 750GB
5400 rpm SATA up to 320GB
Encrypted (FDE/SED) FIPS Opal 7200 rpm 320GB
4
Mobility Solid State up to 256GB
Encrypted Mobile Solid State up to 256GB
4
Dell Fast Response Free Fall Sensor and HDD Isolation (standard on motherboard)
E-Module Bay II Secondary HDD Option
Optical Drive Options DVD-ROM, DVD+/-RW via E-Modular Bay II
Multimedia Options High quality speakers, Stereo headphone/Microphone combo jack, Integrated noise reducing array
microphones, Optional integrated HD video webcam and Dell Webcam Central software
Battery Options 3-cell (32Whr) Lithium Ion battery with ExpressCharge™
6-cell (65Whr) Lithium Ion battery with ExpressCharge™
6-cell (58Wh) 3 Year Limited Hardware Warranty
10
Lithium Ion battery
9-cell (97Wh) Extended battery slice
3-cell (30Whr) E-Modular Bay II Battery
Power Options 65 Watt or 90W AC Adapter, 65W BFR/PVC Free AC Adapter
3
, 90W Auto/Air DC adapter (optional)
Connectivity 10/100/1000 Gigabit Ethernet
Wireless LAN and WiMAX Options:
Intel® Centrino® Advanced-N 6205, Intel® Centrino® Advanced-N + WiMAX 6250
3
, Intel® Cen-
trino® Ultimate-N 6300, Dell Wireless™ 1504 (802.11g/n 1x1), Dell Wireless 1540 (802.11n 2x2)
Mobile Broadband
11
& GPS Options:
Dell Wireless 5630 Multi-mode HSPA-EVDO Mini Card (Gobi™ 3000) with A-GPS
3
, Dell Wireless 5560
Single-mode HSPA Mini Card with A-GPS
3
, Dell Wireless 5802 LTE Mobile Broadband (Verizon-US
only), Dell Wireless 5804 LTE Mobile Broadband (AT&T-US only)
Bluetooth Option:
Dell Wireless 380Bluetooth® 4.0
Ports, Slots & Chassis Network connector (RJ-45), USB 2.0 (1) – 1 USB/eSATA combo; USB3.0 (2), Stereo headphone/Mi-
crophone combo jack, Memory card reader, 34 mm ExpressCard, Docking Connector, VGA, mini
HDMI, 1 Full and 2 Half Mini Card Slots
Optional SmartCard Reader/Contactless SmartCard Reader/Fingerprint Reader, Additional USB 3.0
ports option via E-Modular Bay II
Input Device Options Dual pointing keyboard: standard or backlit; Multi-touch Touchpad
Dimensions & Weight
12
Width: 13.19”/335mm Depth: 8.80”/223.3mm
Height: (front/back) 1.0”/25.4mm to 1.18”/30.1 mm
Bound weight: 3.64 lbs/1.606Kg (with 3-cell battery and airbay and non-backlit keyboard )
Regulatory and Environmental Compliance Regulatory Model: P19S Regulatory Type: P19S001
Energy Star 5.2 (Windows OS)
EPEAT Gold (US/Canada); EPEAT Silver (France, Germany, Sweden)
Systems Management Intel® vPro™ Technology’s advanced management features (optional, requires Intel WiFi® Link
WLAN), TPM 1.2
4
Warranty & Support Services Limited Hardware Warranty
10
Standard 3-year Next Business Day On Site Service after Remote
Diagnosis
5
. Optional 3 year Dell ProSupport oers premium support from expert technicians and
24x7 global availability
5
.
Configuration Services Factory Image load. BIOS Customization. Hardware Customization, Asset Tagging and Reporting.
