Dell M410HD User Manual

40 Using Your Projector
NOTE: Closed caption option is available for NTSC only.
TEST PATTERN—Test Pattern is used to test focus and resolution.
You can enable or disable the Test Pattern by selecting Off, 1 or 2. You can also
invoke the Test Pattern 1 by pressing and holding down and buttons on the
control panel simultaneously for 2 seconds. You can also invoke the test pattern 2
by pressing and holding down and buttons on the control panel
simultaneously for 2 seconds.
FACTORY RESET—Select and press to reset all settings to its factory default, the
warning message below appears.
Reset items include both computer sources and video source settings.
Test Pattern 1:
Test Pattern 2:

Dell M410HD Specifications

General

Projection distance	1 - 12 m
Projection technology	DLP
Contrast ratio (typical)	2100:1
Projector native resolution	WXGA (1280x800)
Lamp power	165 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Audio input	1
Dimensions (WxDxH)	205 x 155 x 75.9 mm
Power requirements	AC 100-240 50-60Hz
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	1 W
AC (power) in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	210 W
Storage temperature (T-T)	0 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	80 - 90 %

Weight and Dimensions

Weight	1180 g
