Removing the processor
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the heat-sink.
NOTE: The processor might still be hot, allow the processor to coll before you start the removal procedure.
About this task
The following images indicate the location of the processor and provide a visual representation of the removal procedure.
Steps
1. Press down and push the release lever away from the processor to release it from the securing tab.
2. Lift the lever upward to lift the processor cover.
CAUTION:
When removing the processor, do not touch any of the pins inside the socket or allow any objects to fall
on the pins in the socket.
36 Field service information
