Dell P2425HE - Technical Specifications; Display features and dimensions; Connectivity and power delivery; Compliance and certifications

DELL 24 USB-C HUB MONITOR - P2425HE
FE ATURE TECHNICAL SPECIFICATION
MODEL Dell 24 USB-C Hub Monitor - P2425HE
DIAGONAL
VIEWING SIZE
60.47 cm (23.8”)
PRESET DISPLAY
AREA (H X V)
527.04 mm x 296.46 mm (20.75” x 11.67”)
PANEL TYPE In-Plane Switching (IPS) technology
DISPLAY SCREEN
COATING
Anti-glare with 3H hardness
MAXIMUM PRESET
RESOLUTION
1920 x 1080
REFRESH RATE Up to 100Hz
VIEWING ANGLE 178° vertical / 178° horizontal
PIXEL PITCH 0.2745 mm x 0.2745 mm
PIXEL PER INCH (PPI) 92.53
CONTRAST RATIO 1,500: 1 (typical)
ASPECT RATIO 16:9
BACKLIGHT
TECHNOLOGY
LED edgelight system
BRIGHTNESS 250 cd/m
2
(typical)
RESPONSE TIME 5ms gray-to-gray (Fast mode)
8ms gray-to-gray (Normal mode)
COLOR SUPPORT Color Gamut: 99% sRGB
Color Depth: Up to 16.7 million colors
TÜV EYE COMFORT Yes, 4-Star
FLICKER FREE Yes
CONNECTIVITY
• 1 x HDMI 1.4 (HDCP 1.4) (Supports up to FHD 1920 x
1080 100Hz TMDS as per specified in HDMI 1.4)
• 1 x DP 1.4 (HDCP 1.4)
• 1 x DP-out (1.4) with MST (HDCP 1.4)
• 1 x RJ45
• 1 x USB 3.2 Gen1 Type-C upstream (Alt. mode with
DP1.4) with up to 90W PD
• 3 x USB 3.2 Gen1 Type-A downstream
• 1 x USB 3.2 Gen1 Type-C downstream with up to 15W
PD (data only)
USB POWER DELIVERY Yes, up to 90W via USB-C upstream (Alt. mode with DP1.4)
port, and up to 15W via USB-C downstream port
ADJUSTABILITY Height: Up to 150 mm (5.9”)
Tilt: -5° ~ 21°
Swivel: -45° ~ 45°
Pivot: -90° ~ 90°
DAISY CHAIN
AVAILABILITY
Yes
DELL POWER
BUTTON SYNC
Yes, via USB Type-C upstream port
DELL DISPLAY
MANAGER
COMPATIBILITY
Yes with Easy Arrange
REMOTE ASSET
MANAGEMENT
Yes
SPECIFICATIONS -
SERVICE / SUPPORT
DETAILS
3 Year Limited Hardware Warranty with Advanced Exchange
Service and Premium Panel Exchange
FE ATURE TECHNICAL SPECIFICATION
VOLTAGE REQUIRED 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 2 A (typ)
ENERGY EFFICIENCY
CLASS (A TO G
SCALE)
D
POWER
CONSUMPTION
(OPERATIONAL)
(TYPICAL)
0.3 W (Off mode)
0.3 W (Standby mode)
1.0 W (Networked Standby mode)
13.9 W (On mode)
180 W (Max)
15.2 W (Pon)
49.8 kWh (TEC)
AUDIO OUTPUT Optional soundbar (sold separately)
HEIGHT WITH STAND
(COMPRESSED ~
EXTENDED)
364.00 mm ~ 496.53 mm (14.33” ~ 19.55”)
WIDTH WITH STAND 538.64 mm (21.21”)
DEPTH WITH STAND 181.75 mm (7.16”)
HEIGHT WITHOUT
STAND
314.23 mm (12.37”)
WIDTH WITHOUT
STAND
538.64 mm (21.21”)
DEPTH WITHOUT
STAND
50.03 mm (1.97”)
WEIGHT (PANEL ONLY
- FOR VESA MOUNT)
3.69 kg (8.13 lbs)
WEIGHT (WITH
PACKAGING)
7.24 kg (15.96 lbs)
SECURITY Security-lock slot (based on Kensington Security Slot™)
COMPLIANT
STANDARDS
• ENERGY
®
STAR certified monitor
• EPEAT
®
GOLD
• EPEAT
®
Climate+
• TCO Certified Displays
• TCO Certified Edge
• RoHS-compliant
• BFR / PVC free monitor (excluding external cables)
• Arsenic-free glass and mercury-free (panel only)
FLAT PANEL MOUNT
INTERFACE
VESA (100 mm x 100mm)
TEMPERATURE
RANGE
Operating: 0°C ~ 40°C (32°F ~ 104°F)
Non-operating: -20° ~ 60°C (-4° ~ 140°F)
HUMIDITY RANGE Operating: 10% ~ 80% (non-condensing)
Non-operating: 5% ~ 90% (non-condensing)
ALTITUDE Operating: 5,000 m (16,404 ft) max
Non-operating: 12,192 m (40,000 ft) max
WHAT’S INCLUDED 1 x Monitor panel
1 x Stand riser and base
1 x Power cord
1 x DP-to-DP cable, 1.8m
1 x USB 3.2 Gen2 Type C-to-C cable, 1.0m
1 x Cable tie
1 x Quick setup guide
1 x Safety, Environmental, and Regulatory Information
D
A
G
