Dell P3221D Teardown Instructions

5
DELL P3221D
The following substances, preparations, or components should be disposed of or
recovered separately from other WEEE in compliance with Article 4 of EU Council
Directive 75/442/EEC.
Capacitors / condensers (containing
PCB/PCT)
No used
Mercury containing components
No used
Batteries
No used
Printed circuit boards (with a surface
greater than 10 square cm)
Product has printed circuit boards (with a
surface greater than 10 square cm)
Component contain toner, ink and
liquids
No used
Plastic containing BFR
No used
Component and waste contain
asbestos
No used
CRT
No used
Component contain CFC, HCFC, HFC
and HC
No used
Gas discharge lamps
No used
LCD display > 100 cm2
Product has an LCD greater than 100 cm2
External electric cable
Product has external cables
Component contain refractory
ceramic fibers
No used
Component contain radio-active
substances
No used
Electrolyte capacitors (height
> 25mm, diameter > 25mm)
Product has electrolyte capacitors (height >
25mm, diameter > 25mm)
3. Tools Required
List the type and size of the tools that would typically can be used to disassemble the
product to a point where components and materials requiring selective treatment
can be removed.
Tool Description:
- Screwdriver (Phillip head) #1
- Screwdriver (Phillip head) #2
- Penknife
- Soldering iron and absorber
2. Product material information

Dell P3221D Specifications

General

Pixel pitch	0.2727 x 0.2727 mm
Screen shape	Flat
Pixel density	93.24 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	31.5 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 90 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	800.98 mm
Viewable size, vertical	392.688 mm
Display number of colors	1.07 billion colors
Viewable size, horizontal	698.112 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1280 x 800, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1440
HDMI	Yes
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	145 W
Power consumption (standby)	0.2 W
Power consumption (typical)	25.1 W
Power consumption (PowerSave)	20.6 W
Package depth	177 mm
Package width	940 mm
Package height	525 mm
Package weight	15600 g
Feet color	Silver
Product color	Black
Market positioning	Business
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	7.5 mm
Bezel width (side)	7.6 mm
Depth (with stand)	230 mm
Width (with stand)	713.4 mm
Height (with stand)	618.8 mm
Weight (with stand)	10700 g
Bezel width (bottom)	17.9 mm
Depth (without stand)	55.3 mm
Height (without stand)	418 mm
Weight (without stand)	6400 g
