Item Connector Description
11 J_VIDEO_REAR Video connector
12 J_COM1 Serial connector
13 J_IDRAC_RJ45 iDRAC7 connector
14 J_CYC System identification connector
15 CYC_ID System identification button
16 J_RISER_2A Riser 2 connector
17 J_RISER_1A Riser 1 connector
18 TOUCH POINT Touch point for holding system board
19 J_RISER_2B Riser 2 connector
20 J_RISER_1B Riser 1 connector
21 J_STORAGE Storage controller card connector
22 J_SASX8 SATA connector
23 J_USB_INT Internal USB connector
24 BAT Battery connector
25 CPU2 Processor socket 2
26 B1, B5, B9, B2, B6, B10 Memory module sockets
27 J_FAN2U_7 Cooling fan connector
28 J_FAN2U_6 Cooling fan connector
29 J_FAN2U_5 Cooling fan connector
30 J_FAN2U_4 Cooling fan connector
31 A1, A5, A9, A2, A6, A10, B3, B7, B11, B4, B8, B12 Memory module sockets
32 J_FAN1U_3 Cooling fan connector
33 J_BP1 Backplane power connector
34 J_FAN1U_2 Cooling fan connector
35 J_FAN1U_1 Cooling fan connector
36 A12, A8, A4, A7, A11, A3 Memory module sockets
37 J_CP Control panel interface connector
38 CPU1 Processor socket 1
39 J_FP_USB Front panel USB connector
40 J_BP_SIG1 Backplane signal connector 1
41 J_BP_SIG0 Backplane signal connector 0
